Product Description:
One of the key features of this product is its Zinc Plated finish,
which provides excellent corrosion resistance and a long-lasting
finish. The Zinc Plated finish also gives the bolt a sleek and
professional look, making it a popular choice for use in machinery
and other industrial applications. Additionally, the bolt is
available in two different colors, Black and Zinc, allowing you to
choose the option that best suits your needs.
The Hex Head Bolt is also designed to be used with a Split Pin
accessory, which helps to prevent the bolt from coming loose over
time. The Split Pin fits through a hole in the threaded shaft of
the bolt and is then bent around the head of the bolt, providing a
secure and reliable fastening solution. This makes the Hex Head
Bolt ideal for use in machinery and other applications where safety
and reliability are paramount.
The Hex Head Bolt is suitable for use in a wide range of
applications in the machinery industry, including the assembly of
engines, gearboxes, and other mechanical components. The bolt is
also commonly used in the construction industry for fastening steel
beams and other structural elements together.
This product is shipped in a sturdy Carton Box, ensuring that it
arrives at your location in excellent condition. The box is
designed to protect the bolts during transit, reducing the risk of
damage or loss. The Transport Package also makes it easy to store
and transport the bolts, allowing you to keep them organized and
accessible when you need them.
Features:
- Product Name: High Standard Black Hex Head Bolts
- Packing: Small Box+carton+pallet
- Grade: 8.8
- Head Style: Hexagonal
- Size: 1/4 Inch
- Trademark: YB
- Commonly referred to as a machine bolt, hex head screw, or hex cap
screw
Technical Parameters:
| d | M8 | M10 | (M10) | M12 | (M12) | (M14) | M16 | (M18) | M20 | (M20) | (M22) | M24 |
| P | 1 | 1 | 1.25 | 1.5 | 1.25 | 1.5 | 1.5 | 1.5 | 1.5 | 2 | 1.5 | 2 |
| a | MAX | 3 | 3 | 4 | 4.5 | 4 | 4.5 | 4.5 | 4.5 | 4.5 | 6 | 4.5 | 6 |
| MIN | 1 | 1 | 1.25 | 1.5 | 1.25 | 1.5 | 1.5 | 1.5 | 1.5 | 2 | 1.5 | 2 |
| c | MAX | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 |
| MIN | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 |
| da | MAX | 9.2 | 11.2 | 11.2 | 13.7 | 13.7 | 15.7 | 17.7 | 20.2 | 22.4 | 22.4 | 24.4 | 26.4 |
| dw | Grade A | MIN | 11.63 | 14.63 | 14.63 | 16.63 | 16.63 | 19.64 | 22.49 | 25.34 | 28.19 | 28.19 | 31.71 | 33.61 |
| Grade B | MIN | 11.47 | 14.47 | 14.47 | 16.47 | 16.47 | 19.15 | 22 | 24.85 | 27.7 | 27.7 | 31.35 | 33.25 |
| e | Grade A | MIN | 14.38 | 17.77 | 17.77 | 20.03 | 20.03 | 23.36 | 26.75 | 30.14 | 33.53 | 33.53 | 37.72 | 39.98 |
| Grade B | MIN | 14.2 | 17.59 | 17.59 | 19.85 | 19.85 | 22.78 | 26.17 | 29.56 | 32.95 | 32.95 | 37.29 | 39.55 |
| k | nominal | 5.3 | 6.4 | 6.4 | 7.5 | 7.5 | 8.8 | 10 | 11.5 | 12.5 | 12.5 | 14 | 15 |
| Grade A | MAX | 5.45 | 6.58 | 6.58 | 7.68 | 7.68 | 8.98 | 10.18 | 11.715 | 12.715 | 12.715 | 14.215 | 15.215 |
| MIN | 5.15 | 6.22 | 6.22 | 7.32 | 7.32 | 8.62 | 9.82 | 11.285 | 12.285 | 12.285 | 13.785 | 14.785 |
| Grade B | MAX | 5.54 | 6.69 | 6.69 | 7.79 | 7.79 | 9.09 | 10.29 | 11.85 | 12.85 | 12.85 | 14.35 | 15.35 |
| MIN | 5.06 | 6.11 | 6.11 | 7.21 | 7.21 | 8.51 | 9.71 | 11.15 | 12.15 | 12.15 | 13.65 | 14.65 |
| k1 | Grade A | MIN | 3.61 | 4.35 | 4.35 | 5.12 | 5.12 | 6.03 | 6.87 | 7.9 | 8.6 | 8.6 | 9.65 | 10.35 |
| Grade B | MIN | 3.54 | 4.28 | 4.28 | 5.05 | 5.05 | 5.96 | 6.8 | 7.81 | 8.51 | 8.51 | 9.56 | 10.26 |
| r | MIN | 0.4 | 0.4 | 0.4 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.8 | 0.8 | 0.8 | 0.8 |
| s | MAX | 13 | 16 | 16 | 18 | 18 | 21 | 24 | 27 | 30 | 30 | 34 | 36 |
| Grade A | MIN | 12.73 | 15.73 | 15.73 | 17.73 | 17.73 | 20.67 | 23.67 | 26.67 | 29.67 | 29.67 | 33.38 | 35.38 |
| Grade B | MIN | 12.57 | 15.57 | 15.57 | 17.57 | 17.57 | 20.16 | 23.16 | 26.16 | 29.16 | 29.16 | 33 | 35 |
Applications:
The Hex Head Bolt is a versatile product that can be used in
various applications. It is commonly used in construction,
automotive, and industrial settings. The product's full-threaded
design makes it easy to install and provides a secure fit. It is
also available in a size of 1/4 inch, making it suitable for
multiple applications.
The Hex Head Bolt is designed with a split pin accessory, ensuring
that it is securely fastened in place. It is graded as 8.8, making
it a high-strength bolt that can withstand heavy loads and
pressure. This product is also available in a bulk quantity, with a
minimum order quantity of 5000 pieces. The pricing is negotiable,
making it accessible to various industries.
The Hex Head Bolt is packaged in a carton box or PE bag, ensuring
its safety during transportation. The delivery time for this
product ranges from 7 to 25 days, depending on the order size.
Payment terms are through T/T, ensuring a secure transaction for
both parties. The supply ability of this product is 500 tons per
month, making it readily available for various projects.
The Hex Head Bolt is an ideal product for different occasions and
scenarios. It is commonly used in construction projects, such as
building bridges, highways, and other infrastructures. It is also
used in automotive settings, such as fastening engine components
and other automotive parts. In industrial settings, the Hex Head
Bolt is used for machinery fastening and other heavy-duty
applications.
Overall, the YONGBIAO GB/DIN/ISO Hex Head Bolt is a reliable and
high-quality product. Its hexagonal bolt design ensures that it can
be fastened securely in place, while its split pin accessory
provides additional security. Its availability in bulk quantity and
negotiable pricing makes it accessible to various industries, while
its certification and high-strength grade ensure its quality and
reliability.
