Product Description and Features:

The advantages of stainless steel 410 with EPDM gasket for stainless steel drill tail screws are:
1, Strong penetrability.

Although the penetration of 410 stainless steel drill tail screws is inferior to that of carbon steel screws, it is significantly better than that of 304 stainless steel screws.
It is mainly suitable for direct fixation of steel structures and color steel tile houses, and can penetrate steel plates with a thickness of 2.5-5mm without pre drilling. It is commonly used in outdoor scenes such as building roof installation that require rapid construction.
‌
2, Good anti rust performance.
410 stainless steel drill tail screws have better rust prevention performance than galvanized carbon steel screws, and the composite gasket they come with can effectively seal and prevent liquid leakage. They are particularly suitable for connecting industrial equipment in humid environments or with corrosive media, such as the construction of roofs in Southeast Asian or coastal residential buildings with high rainfall and humidity;
It can also be used in the connection of various chemical equipment.

3, 410 stainless steel has magnetism, making it easy to install.

Due to the magnetic properties of 410 stainless steel, it can be quickly positioned and installed using magnetic suction tools, greatly improving construction efficiency.

Company Certificate:

Applications

	ADAPTER TO USE: Magnetic Hex Socket 8mm
	STEEL PENERATION:Max.6.0mm thick
	PRODUCT FEATURES:SUS410 With EPDM
	WASHER:EPDM Washer
	SIZE:5.5*25mm,10#
	STANDARD:ISO15480

Technical Parameters:

Mark	According To Customer's Requirement
Size	10#,12#
Drive Type	Hexagonal
Trademark	YB
Payment	TT
Advantage	Durable, high Strength
Quality Control	ISO9001
Grade	ST4.2,ST4.8,ST5.5,ST6.3
Head Type	Hexagonal With EPDM Washer
Service	OEM ODM Customized

D		ST2.9	ST3.5	(ST3.9)	ST4.2	ST4.8	(ST5.5)	ST6.3
P	Thread Pitch	1.1	1.3	1.3	1.4	1.6	1.8	1.8
A	MAX	1.1	1.3	1.3	1.4	1.6	1.8	1.8
C	MIN	0.4	0.6	0.6	0.8	0.9	1	1
dc	MAX	6.3	8.3	8.3	8.8	10.5	11	13.5
	MIN	5.8	7.6	7.6	8.1	9.8	10	12.2
E	MIN	4.28	5.96	5.96	7.59	8.71	8.71	10.95
K	MAX	2.8	3.4	3.4	4.1	4.3	5.4	5.9
	MIN	2.5	3	3	3.6	3.8	4.8	5.3
kw	MIN	1.3	1.5	1.5	1.8	2.2	2.7	3.1
R	MAX	0.4	0.5	0.5	0.6	0.7	0.8	0.9
S	MAX	4	5.5	5.5	7	8	8	10
	MIN	3.82	5.32	5.32	6.78	7.78	7.78	9.78
dp		2.3	2.8	3.1	3.6	4.1	4.8	5.8

Packaging:

Carton Packaging	Outer Cartonbox Packaging	Pallet Packaging
Bolts are packed in neutral packaging boxes, with standard quantities arranged in small cartons. The exact number of units per carton will be confirmed with the customer to align with their specific requirements. Customized packaging configurations are available upon request.	The small cartons are then consolidated into larger master cartons for secure transportation and storage. The quantity per master carton can be customized based on client specifications or aligned with standard logistical requirements.	The palletized units are securely wrapped with waterproof film and reinforced with packaging straps. Customer-specific shipping marks or labels are affixed to each pallet, ensuring clear identification and compliance with logistics requirements. This final packaging stage guarantees weather-resistant protection and stability during transportation.

Ningbo Yongbiao Fastener Manufacturing Co., Ltd. is located in Ningbo, the second largest port city in China. The factory is 50 kilometers away from Ningbo Port and can reach the sea freight warehouse in one hour, with very fast logistics. The company was founded in 2012 and after years of hard work and development, it has become a factory covering an area of over 2000 square meters with a registered capital of 6.8 million yuan. So far, the company has two holding subsidiaries and has gradually developed into a medium-sized fastener manufacturing enterprise integrating research and development, production, and sales. Currently, the factory has more than 50 employees and complete production and testing equipment, including more than 50 production equipment and more than 10 testing equipment. The factory has an annual production capacity of 4000-5000 tons of fasteners and an annual output value of 40-50 million RMB. Our products have a normal delivery time of 20-30 days and a stock time of 1-5 days. Our independent brand "YB" accepts OEM, ODM. Our main products include various fasteners, standard parts, bolts, screws, wood screws, self tapping screws, turning screws, combination screws, nuts, accessories, flat washers, lifting rings, etc. In addition, we also have multiple CNC lathes and milling machines to provide customized fastener services for customers. The company's products are mainly used in the fields of automobiles, machinery, electronic equipment, sheet metal, security, new energy, etc., and have been widely praised by domestic and foreign customers. Welcome new and old customers to inquire.
